Application
The YCZX40 wrap around case packer's production capacity is 35 cases/min, which is suitable for carton packaging on bottle (can) production lines for beer, other beverages, bottled water, medicine, food, and more. With this packaging method, users can save about 1/5 of the cost of packaging materials when compared to traditional packaging methods.

Technical parameters
Model YCZX40
Machine Dimension L10810mm*W4900mm*H2620mm
Formed Carton Dimension Max:480*320*340mm
Min: 264*198*116mm
Capacity 35 cartons/min
Power Supply Capacity 3 Phase 380V 50Hz/13KW
Hot-melt Adhesive Solidify Time 1.5~2S
Working Air Pressure 0.6~0.8Mpa
Machine Weight 7000kg
Bottle Height 116~340mm
Bottle Diameter Φ50~180mm
Features
  • Improves various wrapper packaging control functions, detect errors and display messages automatically for maintenance and guidance with human-computer interaction interface.
  • Uses a well-known electrical control system and servo control system with stable operation and high efficiency.
  • Reasonable cardboard-feeding structure: Cardboard is controlled by the servo control system in batches from tilted to flat, ensuring a stable supply.
  • Linear structure, wide-face feeding mode, carton gluing located on the left and right sides and long holding time to make the carton stronger.
  • Using famous hot melt adhesive equipment, operation is easy, and the equipment is durable. Products are packaged with a neat, beautiful appearance, and are easy to store and transport. easy operation and durability.
