Low profile pallet jacks feature a lower forklift height, making them suitable for pallets or skids with low clearance openings. The low profile pallet jack is rated for a 2T maximum load capacity, and a lifting height of 157mm or 160mm.

Features
  • The low fork height designs broadens product use scope, making it ideal for pallets with special heights.
  • The use of a one-piece cast hydraulic pump ensures no looseness and no leakage.
  • This pallet jack is suitable for a variety of environments, with a typical service life of 3 to 5 years.
  • As it is made of a high-strength alloy steel, it features a large load capacity.
  • Set active safety valve to avoid the overload use.
  • The humanized design ensures a highly efficient, easy operation and lower labor intensity.
Technical parameters
Model SBA-L
Load capacity/rated load Q(kg/lb) 1500 2000
Load center distance C (mm/in) 500 500
load wheels mm/in Φ150 Φ150
steer wheels mm/in Φ50 Φ58
Lifting height h3(mm/in) 157 160
Lowered height h13(mm/in) 55 65
Overall length l1(mm/in) 1547/1617
Fork length s/e/l 1150/1220
Distance between fork-arms b5(mm) 550/680
Turning radius Wa(mm) 1249/1319
